Produced from High Conductivity Copper Tubing; Tin Plated to Provide Corrosion Low Contact Resistance; Marked with Die Index and Color Coded; Listed for 35 Kilovolt Maximum when Properly Installed and to Cable Manufacturer Instructions; For Applications Greater than 2000 Volt, Consult the Cable Manufacturer for Voltage Stress Relief Instructions

Specifications:

Voltage Rating: 600 Volt to 35 Kilovolt
Conductor Material: Copper
Conductor Size: 4/0 AWG
Barrel Type: Long
Barrel Length: 1.42 Inch
Pad Size: 1.06 Inch Length x 1 Inch Width x 0.13 Inch Thickness
Number of Pad Holes: 1
Stud Size: 1/2 Inch
Color: Purple
Die Index: 10/15/1954 12:00:00 AM
Material: Tin Plated Copper
Overall Length: 2.79 Inch
Approval: UL 486A/B, 467, UL (Canada and US)
