RoHS Compliant

Specifications:

Type: Thermal Magnetic
Frame Type: LD
Voltage Rating: 600 Volt AC, 500 Volt DC
Current Rating: 600 Amp
Number of Poles: 3
Interrupting Rating: 100 Kiloamp at 240 Volt AC (UL 489), 65 Kiloamp at 480 Volt AC (UL 489), 35 Kiloamp at 600 Volt AC/500 Volt DC (UL 489), 100 Kiloamp at 220/240 Volt AC (IEC), 65 Kiloamp at 380/415 Volt AC (IEC)
Size: 7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height
Approval: UL 489, IEC
