Manufactured from High Conductivity Seamless Copper Tubing; Tin-Plated to Inhibit Corrosion; Beveled Entry for Easy Cable Insertion; Closed Transition Protects End of Cablefrom Environmental Conditions; Two-Hole Mounting Pad Assures Maximum Secureness; Long Barrel Provides High Pull Out Force and Added Secureness for Improved Mechanical and Electrical Properties; RoHS Compliant; Made in USA

Specifications:

Voltage Rating: 35 Kilovolt
Conductor Material: Copper
Conductor Size: 600 KCMIL
Barrel Type: Long, Straight
Barrel Length: 2.69 Inch
Pad Size: 3 Inch Length x 1.72 Inch Width x 0.27 Inch Thickness
Number of Pad Holes: 2
Pad Hole Spacing: 1.75 Inch
Stud Size: 1/2 Inch
Color: Green
Die Index: 22
Material: Tin Plated Copper
Overall Length: 6.56 Inch
Approval: UL, CSA
