Definite Purpose Contactors are Ideal for HVAC, Heating, Air Conditioning, Refrigeration, Data Processing, Food Service Equipment; Quick Connect Terminals and Binder Head Screws Allow for Easy Wiring; Box Lugs are Standard on Contactors 40 Ampere and Larger; An Exclusive DIN Track Mounting Option May Reduce Installation Costs; Compact Design; Industry Standard Mounting; Double Break Contacts; Straight-Through Wiring 500000 Mechanical Operations; 100000 Electrical Operations on Type DP; Continuous Duty Cycle; Low Cost; RoHS/REACH Compliant; Mercury-Free

Specifications:

Type: Non Reversing
Number of Poles: 3
Power Rating/Voltage: 7-1/2 HP at 115 VAC 1 Phase, 20 HP at 230 VAC 1 Phase, 30 HP at 230 VAC 3 Phase, 50 HP at 460/575 VAC 3 Phase
Current Rating: 90 Ampere
Resistive Ampere: 120 Ampere
Coil Voltage: 110 VAC at 50 Hz, 120 VAC at 60 Hz
Auxiliary Contact: 3NO
Enclosure: Open
Construction Standard: NEMA
Approval: UL, CSA, CE
