Wide Range Taking Ability and Multi Conductor Design Provide Flexibility with a Minimum Number of Parts, Allowing for Conductor to Conductor, Conductor to Rebar and Conductor to Ground rod Applications; Slotted Design Allows Quick and Easy Assembly of Conductor to Connector Using Panduit Cable Ties, Included; Pre Applied Conductive Antioxidant Compound Ensures a High Quality Mechanical and Electrical Bond, Speeding Installation

Specifications:

Shape: E
Conductor Material: Copper
Minimum Run Conductor Size: 1/0 AWG Stranded
Maximum Run Conductor Size: 250 KCMIL
Minimum Tap Conductor Size: 6 AWG Solid
Maximum Tap Conductor Size: 1/0 AWG Stranded
Die Index: PG25
Body Material: Bronze
Approval: UL 467 (Canada and US), CSA C22.2
