Burndy GCL30 Grounding Connector

High Copper Alloy Ground Connector for Joining a Wide Range of Two Parallel Cables to 1/4 Inch Thick Bar; Type GC Separates Cable from Bar, GCM Clamps Cable to Bar Surface; 1-Wrench Installation; The High Copper Alloy Cast Body and Durium Bolts, Nuts, Lock Washer Make the GC and GCM Suitable for Direct Burial in Concrete or Ground; For Two Copper Cables to Bar; RoHS Compliant

Specifications:

Conductor Size: 4 to 4/0 AWG Solid (Copper), 4 AWG Stranded to 300 KCMIL (Copper)
Bolt Size: 1/2 Inch
Bar Thickness: 1/4 Inch
Height: 2 Inch
Material: Cast Copper Alloy Body, Durium Bolt/Nut/Lockwasher
Approval: UL 467, CSA
Used On: (2) Parallel Cable to Bar, Direct Burial
