Short Circuit/Overload Protection; HACR Rated; RoHS/REACH Compliant; Mercury-Free; Green Premium Product

Specifications:

Type: Branch
Voltage Rating: 120/240/277 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz (UL/CSA)
Current Rating: 30 Ampere
Number of Poles: 3
Interrupting Rating: 100 Kiloampere at 120/240 VAC, 65 Kiloampere at 480 VAC Star/277 VAC or 277 VAC (UL/CSA)
Trip Setting: 270 to 875 Ampere
Installation: Bolt-On
Application: Lighting
Used On: Class 515 NF Series Panelboard
Approval: UL, CSA, NOM 117
