Rugged Construction, Reliable Performance, Continuity of Service and Ease of Maintenance are Emphasized; Available Fault Currents Higher than 10000 Amp are Likely to be Encountered, Such as in Manufacturing Plants, Mass Production Industries, and Commercial, Institution-AL and Other Large Buildings Served by Network Systems or Transformers of Higher Capacities; Voidable Dual Cover Interlocks Standard on All Heavy Duty Switches

Specifications:

Type: Fusible, Heavy Duty
Voltage Rating: 240 Volt AC, 250 Volt DC
Current Rating: 60 Amp
Power Rating: 3 HP at 240 Volt AC 1-Phase, 7-1/2 HP at 240 Volt AC 3-Phase, 10 HP at 250 Volt DC
Circuit Configuration: 1-Phase 2-Wire, 3-Phase 3-Wire
Number of Poles: 3
Fuse Type: Class H, Class K, Class R
Operator Type: Insulating Grip
Conductor Material: Copper/Aluminum
Conductor Size: 14 to 3 AWG
Enclosure Material: 304 Stainless Steel
Enclosure Type: NEMA 3R
Terminal Type: Lug
Size: 9.16 Inch Width x 5.05 Inch Depth x 16.26 Inch Height
Approval: UL
