RoHS/Reach/WEEE Compliant

Specifications:

Type: Molded Case, Thermal Magnetic, Low Voltage, Standard Breaking Capacity
Frame Type: ED
Voltage Rating: 600 Volt AC, 500 Volt DC
Maximum AC Voltage Rating: 600 Volt
Maximum DC Voltage Rating: 500 Volt
Current Rating: 60 Amp at 40 Deg C
Number of Poles: 3
Interrupting Rating: 25 Kiloamp at 480 Volt, 18 Kiloamp at 600 Volt
Terminal Type: Load Side Lug
Size: 3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height
Approval: UL 489
