RoHS Compliant; Field Installable External Accessories; Series Connected Short Circuit Ratings; Thermal Magnetic and Solid States

Specifications:

Type: Thermal Magnetic
Frame Type: ED
Voltage Rating: 600 Volt AC, 500 Volt DC
Current Rating: 100 Amp
Number of Poles: 3
Interrupting Rating: 65 Kiloamp at 240 Volt AC (UL 489), 25 Kiloamp at 480 Volt AC (UL 489), 18 Kiloamp at 600 Volt AC/500 Volt DC (UL 489), 65/17 Kiloamp at 220/240 Volt AC (IEC), 35/9 Kiloamp at 380/415 Volt AC (IEC), 18/5 Kiloamp at 500 Volt AC (IEC)
Terminal Type: Load Lug
Size: 3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height
Approval: UL 489, IEC
