Designed for Residential and Light Commercial Applications Where Duty is Not Severe; Listed to UL Standard 98 Enclosed and Dead Front Switches; Suitable for Use as Service Equipment When Installed in Accordance with the National Electrical Code; Certified to CSA Standard 22.2 No. 4-04 Enclosed and Dead Front Switches; Meets or Exceeds NEMA KS1 Standard for Enclosed Switches, Type Gd; 60/75 C Conductor Rating; Direct-Drive, Quick-Make, Quick-Break Mechanism "Snaps" Contacts Open and Closed Providing Positive On/Off Indication; Self-Leveling, Three-Point Mounting System; Visible Confirmation of Plated Blade Contact Positions; Spring Reinforced Fuse Clips Assure Reliable Contact for Cool Operation; Seismic Certified; GSA Compliant

Specifications:

Type: General Duty
AC Voltage Rating: 120/240 V
DC Voltage Rating: 250 V
Current Rating: 200 Ampere
Power Rating: 15 HP at 240 VAC 1-Phase (NEC Standard/Time Delay)
Number of Poles: 2
Number of Wires: 3
Fuse Provision: Fusible
Fuse Type: Cartridge, Class H/K/R
Neutral Type: No
Enclosure: NEMA 1
Size: 13.42 Inch W x 5.2 Inch D x 29.11 Inch H
Approval: UL 98, CSA
