Contoured Wing Design Provides Maximum Torque; Flexible Shell Expands for Smooth, Progressive Tightening Providing Dependable Connections; Expanding, Square Wire Spring Creates Secure Connections; Wide, Deep Skirt Opening Accommodates a Variety of Wire Combinations; RoHS Compliant

Specifications:

Type: Contoured Wing
Voltage Rating: 600 Volt
Wire Size: 18 to 10 AWG
Minimum Wire Combination Size: (6) #18
Maximum Wire Combination Size: (3) #10
Spring Type: Expanding Square Wire
Shell Material: Thermoplastic Polyester
Color: Red
Temperature Rating: 221 Deg F
Standard Package: 500 per Bag
Approval: UL 486C/94V-2, CSA C22.2
