Lead-Free; Space Saving-Typical 3-Pole Class T Fuse Blocks Require Less than 50 Percent of the Panel Area Required for Class R Fuse Blocks; Reliable Interruption of All Over Currents; Extremely Current Limiting-Stops Damaging Short Circuit Current Faster than any Mechanical Protective Device; Fast Acting Provides Fast Acting Overload Protection to Equipment Such as Variable Speed Drives, Rectifiers and Other Equipment Containing Surge-Sensitive Components; Current Limiting Design Greatly Reduces Damage to Equipment Caused by Heating and Magnetic Effects of Short Circuit Currents; RoHS Compliant

Specifications:

Type: Class T
Characteristics: Fast Acting
Voltage Rating: 300 Volt AC, 125 Volt DC
Current Rating: 100 Amp
Interrupting Rating: 200 Kiloamp Symmetrical (AC), 20 Kiloamp (DC)
Terminal Type: Blade
Diameter: 0.812 Inch
Length: 2.156 Inch
Approval: UL 248-15, CSA, CE
