Ilsco AK-500 Split Bolt Connector

Provides Maximum Conductivity and Strength for Copper and Aluminum Conductors; Bite into the Conductor to Break Through Surface Oxides; Which Eliminates Wire Brushing; Application Versatility; Provides Low Contact Resistance; Separates Dissimilar Metals Which Prevents Galvanic Corrosion; Provides Ease of Installation with Standard Wrenches; Triangular Edges; RoHS Compliant

Specifications:

Voltage Rating: 2000 V
Installation: Hex Head Split Bolt with Spacer Bar
Conductor Material: Aluminum/Copper
Minimum Run Conductor Size: 400 KCMIL (Compact)
Maximum Run Conductor Size: 500 KCMIL (Compact)
Minimum Tap Conductor Size: 2 AWG Stranded (Compact)
Maximum Tap Conductor Size: 500 KCMIL (Compact)
Material: Electro-Tin Plated Heat Treated Aluminum Alloy
Approval: UL 670B, CSA
