PowerMark Gold load centers lower your costs by making installation faster and easier, increasing application flexibility and reducing inventory requirements. At the same time, they deliver obvious and significant advances in design, function and quality.

Specifications:

Type: Main Breaker
Voltage Rating: 120/240 VAC
Current Rating: 60 Ampere
Circuit Configuration: 1-Phase 3-Wire
Maximum Number of Circuits: 8
Maximum Number of Spaces: (4) 1-Pole 1 Inch THQL/(2) 2-Pole 1 Inch THQL/(8) 1-Pole 1/2 Inch THQP/(4) 2-Pole 1/2 Inch THQP
Main Breaker Type: THQL/THQP
Breaker Mounting: Plug-In
Interrupting Rating: 22 Kiloampere
Bus Material: Copper
Feed Location: Top/Bottom
Main Wire Size: 6 to 1 AWG (Copper/Aluminum)
Enclosure Type: NEMA 1, Indoor
Cover Type: Flush
Enclosure Size Designation: 3A
Size: 11-9/16 Inch W x 3-3/8 Inch D x 11-3/8 Inch H
Approval: UL
