RoHS Compliant

Specifications:

Type: Molded Case, Thermal Magnetic
Frame Type: FD
Voltage Rating: 600 Volt AC at 50/60 Hertz, 500 Volt DC
Maximum AC Voltage Rating: 600 Volt
Maximum DC Voltage Rating: 500 Volt
Current Rating: 250 Amp at 40 Deg C
Number of Poles: 3
Interrupting Rating: 25 Kiloamp at 600 Volt AC, 25 Kiloamp at 500 Volt DC
Terminal Type: Line and Load Lug
Size: 4.5 Inch Width x 5.25 Inch Depth x 9.5 Inch Height
Approval: UL, CSA, CE, IEC
