Clampmatic Arc Control Hazardous Switching; NEMA Phasing; Pressure Terminal Connector; Connection Screw; Quick-Make Quick-Break; Easy Mounting; Padlocking Member; Fiber End Barrier; High Pressure Spring Reinforced Copper Fuse Clip; Voidable Cover Interloc

Specifications:

Type: Single
Voltage Rating: 600 Volt AC, 250 Volt DC
Current Rating: 400 Ampere
Power Rating: 100 HP at 480 VAC, 125 HP at 600 VAC (Standard), 250 HP at 480 VAC, 350 HP at 600 VAC (Maximum)
Number of Poles: 3
Wire Size: (2) 4 AWG to 500 KCMIL
Size: 17 Inch Width x 10-1/2 Inch Depth x 15 Inch Height
Used On: SB1/SB2 Switchboard and F1/F2 Panelboard
Approval: UL 98
