1-Piece Interior Removes and Reinstalls Easily; Full-Length Neutrals are Easier to Wire Reducing Installation Time and Cost; Minimum 100% Neutral Terminations; Sturdy Copper Bus and Galvanized Box Increase Durability and Reliability; Main Breaker Configuration Allows Top or Bottom Feed without Modification; Combination Slotted/Robertson Square-Drive Speeds Screw Wiring; 100% Rated Split Neutral on Each Side; Tie Bar May be Removed to Split Neutral/Ground

Specifications:

Type: Main Lug
Voltage Rating: 208 VAC Star/120 VAC
Current Rating: 150 Ampere
Circuit Configuration: 3-Phase 4-Wire
Maximum Number of Circuits: 18
Maximum Number of Spaces: (18) 1-Pole 1 Inch THQL/(8) 2-Pole 1 Inch THQL/(6) 3-Pole 1 Inch THQL
Breaker Mounting: Plug-In
Interrupting Rating: 22 Kiloampere
Neutral Type: Split
Feed Location: Top/Bottom
Main Wire Size: 1 to 3/0 AWG (Copper), 2/0 to 3/0 AWG (Aluminum)
Enclosure Type: NEMA 1, Indoor
Cover Type: Flush/Surface
Enclosure Size Designation: 7
Size: 14 Inch W x 3-3/4 Inch D x 24-11/16 Inch H
Approval: UL
