1-Piece Interior Removes and Reinstalls Easily; Full-Length Neutrals are Easier to Wire Reducing Installation Time and Cost; Minimum 100% Neutral Terminations; Sturdy Copper Bus and Galvanized Box Increase Durability and Reliability; Main Breaker Configuration Allows Top or Bottom Feed without Modification; Combination Slotted/Robertson Square-Drive Speeds Screw Wiring; 100% Rated Split Neutral on Each Side; Tie Bar May be Removed to Split Neutral/Ground

Specifications:

Type: Main Lug
Voltage Rating: 120/240 VAC
Current Rating: 125 Ampere
Circuit Configuration: 1-Phase 3-Wire
Maximum Number of Circuits: 8
Maximum Number of Spaces: (4) 1-Pole 1 Inch THQL/(2) 2-Pole 1 Inch THQL/(8) 1-Pole 1/2 Inch THQP/(3) 2-Pole 1/2 Inch THQP
Breaker Mounting: Plug-In
Interrupting Rating: 10 Kiloampere
Neutral Type: Split
Feed Location: Top
Main Wire Size: 1 to 2/0 AWG (Copper/Aluminum)
Enclosure Type: NEMA 3R, Outdoor
Enclosure Size Designation: R1
Size: 7-1/2 Inch W x 3-5/16 Inch D x 9-7/32 Inch H
Approval: UL
