Break before Make Switch Mechanism; All-in-One Construction with Factory-Assured terminations; Bus Bars Interconnect Main and Standby Switches; G90 Galvanized Steel Construction for Superior Corrosion Protection; Durable Polyester Powder Coat Finish Resists Chipping and Fading; High quality, User-Tested Components Designed for Long Life; Interlock Allows Door Opening Only When Switch is in the Off Position; Padlock Provision on Door; Optional Neutral Kits Available for Both 240 V and 600 V Models

Specifications:

Type: Manual
Voltage Rating: 120/240 VAC 1-Phase
Main Current Rating: 200 Ampere
Emergency Current Rating: 200 Ampere
Short Circuit Rating: 10000 Ampere
Wire Type: Aluminum/Copper
Wire Size: 6 AWG to 250 KCMIL
Enclosure: NEMA 3R
Height: 35 Inch
Width: 15-3/4 Inch
Depth: 7 Inch
Application: Generator
Approval: UL (Canada and US)
