Scheduling 99 on and Off Set Points Allow Individual Programs for Each Day of the Week at a Minimum 1 Minute Apart; Seasons 1 to 4 with Different Daily Schedules Which can Wrap Around into the New Year; Signal/Pulse Duration 2 Different Settings Per Channel Each 1-99 Seconds; Daylight Saving Automatic Adjustment Daylight Saving Automatic Adjustment; Leap Year Automatic Compensation; Manual Override Until the Next Regularly Scheduled ON or OFF, Automatic Operation then Resumes; In Signal Mode, Activates Pulse; Clock Format; Power Outage Backup Permanent Schedule Retention with Memory Module; Supercapacitor Provides 7 Days of Real Time Backup; Memory Module Removable can be Programmed at any One Location and Inserted into Another DZS Series Unit; Enhanced Switching Inrush Current Limiting Technology Protects Relay Contacts for Extended Life with Zero Cross Type Switching

Specifications:

Type: 365/7 Day Astronomic
Maximum Number of Operations: 99 per Day
Number of Circuits: 1
Switch Type: DPDT
Current Rating: 30 Ampere at 24 to 277 VAC (General Purpose, NO/NC), 30 Ampere at 120 VAC (Ballast, NO), 10 Ampere at 120 VAC (Ballast, NC), 15 Ampere at 120 to 277 VAC (Tungsten, NO), 2 Ampere at 120 to 277 VAC (Tungsten, NC), 30 Ampere at 28 VDC (Resistive, NO/NC)
Voltage Rating: 120/208 to 240/277 VAC at 50/60 Hz
Power Rating: 1 HP at 120 VAC (Motor Load, NO/NC), 2 HP at 208 to 277 VAC (Motor Load, NO/NC), 720 VA at 120 to 277 VAC (Pilot Duty, NO/NC)
Reserve Power: Super Capacitor 7 Days
Operating Temperature: -40 to 158 Deg F
Enclosure: NEMA 3R
Material: Noryl
Size: 5-1/4 Inch W x 4-5/16 Inch D x 8-1/4 Inch H
Application: HVAC Equipment, Horns and Bell, Interior Lighting, Electronic Motor, Outdoor Lighting and Sign
Approval: UL (Canada and US)
