1-Piece Interior Removes and Reinstalls Easily; Full-Length Neutrals are Easier to Wire Reducing Installation Time and Cost; Minimum 100% Neutral Terminations; Sturdy Copper Bus and Galvanized Box Increase Durability and Reliability; Main Breaker Configuration Allows Top or Bottom Feed without Modification; Combination Slotted/Robertson Square-Drive Speeds Screw Wiring; 100% Rated Split Neutral on Each Side; Tie Bar May be Removed to Split Neutral/Ground

Specifications:

Type: Main Lug
Voltage Rating: 120/240 Volt AC
Current Rating: 70 Amp
Circuit Configuration: 1-Phase 3-Wire
Maximum Number of Circuits: 4
Maximum Number of Spaces: (2) 1-Pole 1 Inch, (1) 2-Pole 1 Inch/2-Pole 1/2 Inch, (4) 1-Pole 1/2 Inch
Interrupting Rating: 22 Kiloamp
Bus Material: Tin Plated Copper
Feed Location: Top
Main Wire Size: 6 to 3 AWG (Copper/Aluminum)
Enclosure Type: NEMA 3R, Outdoor
Enclosure Size Designation: R1A
Size: 7-1/4 Inch Width x 3-3/4 Inch Depth x 10 Inch Height
Approval: UL
