Electronics Accurately Identify Excessive Current or Phase Loss and React to Conditions with Greater Speed, Reliability and Repeatability than Traditional Electromechanical Device; Integral Ground Fault Protection Supporting True Simultaneous Ground Fault Protection and Communications an Industry First, Translates to Reduced Inventory, Quicker Installation Time and a Reduced Physical Footprint; Remote Monitoring Capabilities to Discover Changes in Your System, Protects Against Unnecessary Downtime; LED Indicator Provides Predictive Indication Which Allows Users to Determine the Status of the Overload as Well as an Impending Trip to Provide Enhanced Protection of Your Most Important Assets; Patented thermal Modeling Design Results in Increased Motor Life

Specifications:

Type: Adjustable Trip Class, Bi-Metallic, Thermal
Motor FLA: 32 Amp
Number of Poles: 3
Trip Class: Class 10, Class 20
NEMA Size: 00, 0
IEC Size: A to F
Reset Type: Manual/Automatic
Ambient Temperature: Compensated
Auxiliary Contact: 1NO-1NC
Contact Rating: 600 Volt AC 5 Amp (NC), 600 Volt AC 2.5 Amp (NO)
Terminal Type: Load Lug
Mounting: Contactor/DIN Rail
Enclosure: Open
Approval: UL, CSA, CE
