Pass & Seymour CSB20AC4GRY AC Toggle Switch

Out of stock
SKU: 9129
Regular price $34.84

One-piece brass alloy contact arm for reliable electrical performance; One-piece steel strap with integral ground is plated for corrosion resistance; High strength thermoplastic polycarbonate toggle resists breaking and chipping under heavy abuse; Heavy-duty toggle bumpers for smooth and quiet operation; Back body made of glass-reinforced nylon. Locking support provides resistance to face and back body separation; Available with side wire or external screw-pressure-plate back and side wire models capable of accepting #14 - #10 AWG copper or copper-clad wire; Cam designed for fast make with positive break action to minimize arcing and prolong switch life; Oversized silver alloy contacts for longer dependable switch life; Tri-drive terminal and mounting screws; For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here; RoHS Compliant

Specifications:

Type: Toggle
Current Rating: 20 Amp
Voltage Rating: 120/277 Volt AC
Power Rating: 1 HP and 2 HP
Operation Type: 4-Way
Material: Glass Reinforced Nylon (Back Body), Nylon (Front Body), Thermoplastic Polycarbonate (Toggle)
Color: Gray
Wiring: Back, Side
Size: 1.32 Inch Width x 1.073 Inch Depth x 3.281 Inch Height
Wall Plate Included: No
Application: Hard Use, Specification Grade
Approval: UL 20, CSA C22.2
