Epoxy Encapsulated; Laminations of High Quality Silicon Steel to Minimize Core Losses and Optimize Performance; Molded-In Terminals for Maximum Durability; RoHS Compliant

Specifications:

Primary Voltage: 240 x 480 V, 230 x 460 V, 220 x 440 V
Secondary Voltage: 120/115/110 V
Frequency Rating: 50/60 Hz
Power Rating: 75 VA
Insulation Class: 105
Terminal Type: Screw
Temperature Rise: 55 Deg C
Size: 3 Inch W x 4.03 Inch D x .03 Inch H
Applicable Standard: ANSI, NEMA ST-1, IEEE
Approval: UL, UL (Canada and US), CSA
