Bussmann series fuses play a major role in industrial or commercial facilities by providing reliable, maximum protection to power systems. Their physical size or rejection features prevent replacing a fuse with one from another fuse class. This helps ensure the correct replacement fuse is always installed and the voltage and interrupting ratings remain the same.

Specifications:

Type: Glass Tube
Characteristics: Fast Acting
Voltage Rating: 250 Volt AC, 32 Volt DC
Current Rating: 1-1/2 Amp
Interrupting Rating: 100 Amp at 250 Volt AC, 10000 Amp at 125 Volt AC
Terminal Type: Ferrule
Diameter: 1/4 Inch
Length: 1-1/4 Inch
Approval: UL 248-14, CSA
