EVOCHARGE offers a range of premium EV charging stations and cable management solutions. EVOCHARGE has a dedicated team supported by our parent company, Phillips and Temro Industries, with over 100 years of automotive experience. With US based company and testing, you can feel safe using EVOCHARGE products within your home.

A Faster Choice in EV Charging

Streamline your electric vehicle charging at home with a safe, reliable and cost effective EV charger. See the many advantages to purchasing an EVOCHARGE Level 2 charging station:

- Significantly reduce your charge time compared to Level 1 chargers
- All models can be plug-in power connection or hardwired by a licensed electrician
- Eliminate safety concerns with full UL safety certification: UL File Number E469990 (2/15/2018)
- Reduce cable damage and tripping hazards with the included cable & plug holster
- Manufactured by a responsive US based company
- Invest in a high quality, long-lasting charger conveniently located in your home

Specifications:

Part Numbers: EVC3AA0A2E1A1, EVC3AA0B2E1A1
Connector/EVSE Leve: SAE J1772; AC Level 2
Max Output Rating: 32A; 7.68 kW Maximum Output – For use with dedicated 40A (or greater) Supply Circuit
Alternate Adjustable Output Settings: 24A; 5.76 kW Maximum Output – For use with 30A Circuit Rating 16A; 3.84 kW Maximum Output – For use with 20A Circuit Rating
Electrical Circuit / Input Power Requirements: 208-240VAC, 50/60 Hz., Single Phase; Circuit Requirement: Dedicated; Branch Breaker: Double pole; Circuit Conductors: Line 1, Line 2, Earth Ground
Input Power Connection: Plug-in, NEMA 6-50 Plug (Removable for Hardwire Connection)
Operational Ratings: NEMA 4, Indoor/Outdoor Rated; Temp: -22⁰F to 122⁰F (-30⁰C to 50⁰C); Humidity: 95% RH
Mounting: Wall or Pedestal Installation
Dimensions: 11.0 x 7.5 x 3.2 inches (28.0 x 19.0 x 8.1 cm)
Weight: EVSE 18 ft.: 14 lbs., EVSE 25 ft.: 16 lbs.
Display & Indicators: LED Charge Status Indicators (Power/Ready, Charging, Fault)
Cable Management Type: Connector/Cable Holster (Standard); EVoReel & Retractor Cable Management (Optional)
Standards & Compliance: Charging Station: UL/cUL Listed; SAE J1772, UL 2594, UL 355, CSA
